"The load calculations for our 18-meter bay spacing were exact. We did not have to rework a single column footing during the pour."
Project Director, Port Klang Distribution Hub
Structural review, 2024
Dominiqueribes delivers strict technical blueprints and structural planning for corporate logistics facilities across Malaysia. Led by Dominique Ribes, the firm focuses on load-bearing frameworks, foundation design, and construction-ready documentation for B2B clients. Every drawing is checked against site conditions and local building requirements before it reaches the contractor.
Technical documents and structural studies that support the planning of large-scale logistics warehouses. Each reference covers a specific stage of the design process, from site assessment to material selection.
Load distribution calculations for high-bay racking systems. The framework assumes a clear span of 36 meters with a roof pitch of 4 degrees, and the column grid is set at 12 by 24 meters to keep deflection within serviceability limits.
Soil bearing capacity reports for the Iskandar Puteri area. The borehole logs indicate a stiff clay layer at 2.8 meters depth, which supports a shallow foundation solution without the need for piling on most of the site.
Steel connection details for portal frame structures. The moment connections at the eaves are designed with end plates and high-strength bolts, and the base plates are detailed for grouted pockets to simplify site erection.
Concrete mix specifications for floor slabs under heavy forklift traffic. The slab is designed as a jointed reinforced pavement with a thickness of 180 millimeters and a characteristic strength of 32 megapascals at 28 days.
Project owners and site leads share how our structural blueprints held up during construction and after handover.
